WJ-NX400K/G   Panasonic Network Disk Recorder H265/H264 (By Order 45-60 Days)

Pre-installed  64 Channels Max Expand up to 128 Inputs  (Pre-Order 45-60 Days)

Secure communication and high compression recording

  • Significant reduction of storage space usage through H.265 and Smart Coding.
  • 64 ch. max expandable to 128 ch. camera input                                                                          Option : Additional purchase license for 32 camera :WJ-NXE40W
  • Supports H.265 / H.264 mixed recordings.
  • Scalable storage :  9 integrated drive-bays RAID 1 / 5 / 6
  • **Additional RAID Kit license is necessary to use the RAID feature.
  •  9x HDDs can be installed,up to 6 TB will be supported  Maximum  54 HDD slots                               (with 5x WJ-HXE400 Extension Units, 9x HDDs installed in a extension unit)
  • External storage expansion up to max. 324 TB   (Not include Harddisk)
  • Secure high bandwidth recording  640 Mbps total through put (including 384 Mbps recording bandwidth)
  • Symantec device certificates pre-installed *Secure Communication Kits are necessary.

PC-less non-VMS surveillance solution

  • No camera license fees with a default number of cameras; no annual license updates required.
  • Built-in GUI and Dual HDMI (4K/FHD) outputs
  • Automatic camera configuration
  • Time-saving playback: High-speed(Max. 4x*) all frames playback when there is no motion; normal-speed playback when there is motion. *It depends on resolution and number of screens.
  • Image search with thumbnails
  • High-speed copy to USB storage

High reliability and redundancy

  •  Dynamic HDD power management increases HDD life
  •  Redundant fail-over using 2nd recorder to enable seamless mission-critical recording                          ** Available after version upgrade-
  •  TURBO-RAID for quick RAID recovery without sacrifcing recording bandwidth and performance



WJ-NX400 เครื่องบันทึกเน็ตเวิร์ก 64 ช่อง Panasonic NVR 64 Ch.,9 HDD


    (รวมภาษี, include VAT)
